ROTEX GS 42 AL-H Clamping Hub DH 7.6, Bore Ø 24 mm H7 with Keyway - KTR 550427152476

KTR ✓ Original product Brand new Made in Germany

Secure clamping connection for the backlash-free servo coupling: ROTEX GS 42 AL-H clamping hub DH 7.6, bore Ø 24 mm H7. For servo hydraulics, test benches and automation, where zero backlash and positioning accuracy count.

Net
€223.87
excl. VAT
Item KTR-550427152476
Manufacturer no. 550427152476
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Bore Ø 24 mm H7, size 42, version 7.6: the clamping hub DH connects the shaft to the backlash-free ROTEX GS. Within the coupling, the spider with convex teeth, fitted under pre-tension, ensures backlash-free running.

Benefits

  • Bore Ø 24 mm H7 fully machined
  • Keyway for additional positive-locking drive
  • Backlash-free torque transmission through the pre-tensioned spider
  • Absorbs radial, axial and angular offset between the shafts
  • Component weight 0.893 kg

Applications

Built for servo hydraulics, test benches and automated axes with high demands on zero backlash and positioning accuracy. Matching hubs and spiders of the same size 42 are available separately.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size42
ComponentClamping hub DH
CodeAL-H
VersionDH 7.6
BoreØ 24 mm
Bore toleranceH7
Keywayyes
Weight0.893 kg
HS code84839089
KTR article no.550427152476
Hersteller-Nr550427152476
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
Bore (mm)24

Downloads

Datasheet

User Manual

Catalogue

Brochure
