ROTEX GS 42 Intermediate Tube ZR3 LR 1489 mm with 2 Bonded Hubs - KTR 550420941489

KTR ✓ Original product Brand new Made in Germany

Bridges the shaft gap without backlash: ROTEX GS 42 intermediate tube ZR3 with a 1489 mm tube length LR and two bonded hubs. For servo hydraulics, test benches and automation that demand accurate positioning.

Net
€905.56
excl. VAT
Item KTR-550420941489
Manufacturer no. 550420941489
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For drives with a shaft gap, KTR supplies the ROTEX GS 42 as a ZR3 intermediate tube, here with a tube length LR of 1489 mm. Zero backlash comes from the pre-tensioned spider, whose convex teeth engage the concave jaws of the hubs.

Benefits

  • Bridges the gap between the shaft ends with LR 1489 mm
  • Supplied with 2 bonded hubs as a ready-to-fit unit
  • Backlash-free torque transmission through the pre-tensioned spider
  • Absorbs radial, axial and angular offset between the shafts

Applications

Built for servo hydraulics, test benches and automated axes with high demands on zero backlash and positioning accuracy. Check dimensions and the combination with hubs and spider for size 42 against the KTR dimension sheet before ordering.

Technical data

ManufacturerKTR
SeriesROTEX GS
Size42
ComponentIntermediate tube ZR3 with 2 bonded hubs
Tube length LR1489 mm
HS code84839089
KTR article no.550420941489
Weight0.71 kg
Hersteller-Nr550420941489
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany

Downloads

Datasheet

User Manual

Catalogue

Brochure
