ROTEX GS 24 Clamping Ring Hub Light AL-H Design 6.0 Bore Ø 20 H7 - KTR 550247152090

KTR ✓ Original product Brand new Made in Germany

For the ROTEX GS 24: clamping ring hub light AL-H design 6.0, bore Ø 20 H7. The clamping ring grips the Ø 20 mm shaft frictionally and without play. Combines with any size 24 GS spider.

Net
€88.18
excl. VAT
Item KTR-550247152090
Manufacturer no. 550247152090
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

For the ROTEX GS 24: clamping ring hub light AL-H design 6.0, bore Ø 20 H7. The clamping ring grips the Ø 20 mm shaft frictionally and without play.

Benefits

  • Bore Ø 20 mm to tolerance H7, ready to fit
  • Backlash-free torque transmission together with the pre-tensioned size 24 GS spider
  • Compensates angular, radial and axial misalignment together with the spider

Applications

Shaft connection of servo motors, pumps and measuring shafts in servo hydraulics, test benches and automation. For a complete ROTEX GS 24, add a second hub and a spider to this clamping ring hub light with Ø 20 mm bore.

Technical data

SeriesROTEX GS
Size24
ComponentClamping ring hub light
Hub versionAL-H
Design6.0
BoreØ 20 mm
Bore toleranceH7
Catalogue designationROTEX GS 24 AL-H clamping ring hub light 6.0 Ø20H7
KTR article no.550247152090
Customs tariff no.84839089
Weight0.184 kg
ManufacturerKTR
Hersteller-Nr550247152090
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungSpannringnabe light
Bauform6.0
Bore (mm)20
