ROTEX GS 24 Clamping Ring Hub 6.0 Bore Ø 15 mm H7 - KTR 550240151580

KTR ✓ Original product Brand new Made in Germany

The ROTEX GS 24 clamping ring hub connects the shaft to the pre-tensioned spider, bore Ø 15 mm H7. The clamping ring connects the hub to the Ø 15 mm shaft by friction.

Net
€101.62
excl. VAT
Item KTR-550240151580
Manufacturer no. 550240151580
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

This clamping ring hub forms one half of the ROTEX GS 24. The clamping ring connects the hub to the Ø 15 mm shaft by friction. Because the ROTEX GS spider is fitted under pre-tension, its convex teeth engage the concave hub jaws without play.

Benefits

  • Bore Ø 15 mm H7 for an accurate shaft fit
  • No reversal backlash thanks to the pre-tensioned spider
  • Combines with GS 24 spiders in 92 Sh-A

Applications

It is specified in automation, on test benches and in servo hydraulics when readings and positions must be free of reversal backlash.

Technical data

ManufacturerKTR
Article number550240151580
SeriesROTEX GS
SizeGS 24
ComponentClamping Ring Hub
Hub design6.0
BoreØ 15 mm H7
Customs tariff number84839089
Weight0.71 kg
Hersteller-Nr550240151580
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungSpannringnabe 6.0, Bohrung Ø 15 mm H7
Bore (mm)15

Downloads

Datasheet

User Manual

Catalogue

Brochure
