ROTEX GS 16 spider 64 Shore D green, inner Ø 14 mm, backlash-free servo coupling - KTR 550161000025

KTR ✓ Original product Brand new Made in Germany

This spider in green with 64 Shore D is the elastic element of the backlash-free ROTEX GS 16. The convex teeth of the ROTEX GS 16 64 Shore D spider sit in the concave hub jaws and compensate shaft misalignment.

Net
€8.36
excl. VAT
Item KTR-550161000025
Manufacturer no. 550161000025
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

This spider in green with 64 Shore D is the elastic element of the backlash-free ROTEX GS 16. ROTEX GS stands for backlash-free servo couplings.

Benefits

  • Shore hardness 64 Shore D for the required stiffness and damping of the ROTEX GS 16
  • Pre-tension of the convex teeth for backlash-free torque transmission
  • Compensates angular, radial and axial misalignment
  • Colour green to identify the Shore hardness during assembly
  • Inner diameter Ø 14 mm

Applications

Servo drives requiring precise positioning that use a ROTEX GS 16.

Technical data

ManufacturerKTR
KTR part number550161000025
SeriesROTEX GS
Size16
ComponentSpider
Shore hardness64 Shore D
Colourgreen
Inner diameterØ 14+0.2 mm
Weight0.01 kg
Customs tariff number84839089
Manufacturer designationRotex GS 16 Zahnkranz 64 Sh-D-GS grün Innen D.14+0,2
Hersteller-Nr550161000025
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
Bore (mm)14
