ROTEX GS 9 clamping hub C AL-H pilot bored Ø 2 mm - KTR 550097160250

KTR ✓ Original product Brand new Made in Germany

Pilot bored to Ø 2 mm, the ROTEX GS 9 clamping hub takes your shaft once bored out. Its counterparts are the ROTEX GS 9 spiders.

Net
€20.77
excl. VAT
Item KTR-550097160250
Manufacturer no. 550097160250
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Pilot bored to Ø 2 mm, the ROTEX GS 9 clamping hub takes your shaft once bored out. ROTEX GS stands for backlash-free servo couplings.

Benefits

  • Backlash-free torque transmission in the ROTEX GS 9 via the pre-tensioned spider
  • Pilot bore Ø 2 mm as starting point for the finish bore
  • Clamping hub design C for mounting on the shaft
  • Compensates angular, radial and axial misalignment between the shafts

Applications

Servo hydraulics, test benches and automation where the ROTEX GS 9 must run backlash-free and position accurately.

Technical data

ManufacturerKTR
KTR part number550097160250
SeriesROTEX GS
Size9
ComponentClamping hub
DesignC
Hub codeAL-H
Borepilot bored Ø 2 mm
Weight0.01 kg
Customs tariff number84839089
Manufacturer designationRotex GS 9 AL-H Klemmnabe C D.2 vorgebohrt
Hersteller-Nr550097160250
Zolltarifnummer84839089
GPSR HerstellerdatenKTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Country of ManufactureGermany
AusführungKlemmnabe C
Bore (mm)2
