ROTEX 125 Spider 98 Sh-A T-PUR, purple - KTR 021251000042
Elastomer spider 98 Sh-A in T-PUR (purple), the flexible drive element of the ROTEX 125 jaw coupling. Hardness sets torque, stiffness and damping.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
ROTEX is a torsionally flexible jaw coupling from KTR. It transmits torque positively through an elastomer spider between two jaw hubs and compensates angular, radial and axial shaft misalignment. If the spider wears, the jaws engage with each other so the coupling stays fail-safe.
Benefits
- Hardness 98 Sh-A sets the balance of torque, torsional stiffness and damping
- Compensates shaft misalignment together with the hubs
- Fail-safe and backlash-free through radial pre-tension
Applications
Drives with electric motors, pumps and gearboxes. Wear and spare part, matched to the ROTEX 125 hub size.
Technical data
| Size | ROTEX 125 |
|---|---|
| Material | T-PUR |
| Hardness | 98 Sh-A |
| Colour | purple |
| Temperature range | -20 °C to +130 °C |
| Weight | 1.56 kg |
| Manufacturer | KTR |
| Hersteller-Nr | 021251000042 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Series | ROTEX |
| Shore hardness | 98 Sh-A |
