ROTEX 24 Hub sintered metal, bore 14 - KTR 020242151471
Coupling hub for the ROTEX 24 jaw coupling in sintered metal, finish-bored to 14 mm. Mounts on the shaft and transmits torque through the spider.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
ROTEX is a torsionally flexible jaw coupling from KTR. It transmits torque positively through an elastomer spider between two jaw hubs and compensates angular, radial and axial shaft misalignment. If the spider wears, the jaws engage with each other so the coupling stays fail-safe.
Benefits
- Sturdy hub for durable torque transmission
- Prepared ready to fit
- Combines with any ROTEX 24 spider
Applications
A complete coupling needs two hubs and one spider of size 24.
Technical data
| Size | ROTEX 24 |
|---|---|
| Material | sintered metal |
| Bore | 14 mm |
| Keyway | DIN 6885/1 |
| Weight | 0.49 kg |
| Manufacturer | KTR |
| Hersteller-Nr | 020242151471 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | KTR Systems GmbH, Carl-Zeiss-Straße 25, DE-48432 Rheine, www.ktr.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Germany |
| Norm | DIN 6885-1 |
| Series | ROTEX |
| Bore (mm) | 14 |
