Industrial Pt100 temperature sensor for -50 to +200 °C with the converter built into its 3 m cable. It plugs straight into a 1-Wire UNI RJ11 port, no separate converter needed. Suited to outdoor sites, refrigeration, pharma, food and agriculture.
Pt100 temperature sensor 1WU-Temp Pt100 3m, -50 to +200 °C, IP67, in-cable converter, 1-Wire UNI - HW group 600907
HW GROUP
Original product
Net price (excl. VAT)
€139.20
Item
HWG-600907
Manufacturer no.
600907
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.600907
Country of originCzechia
Customs tariff number90259090
ConditionNew
Artikel
HWG-600907
Frequently Bought Together
-
This Item:
€139.20
-
Bi-metallic thermometer, rear G 1/2, Immersion shaft length 63 mm - Riegler 102773
€58.38
-
Mini resistance thermometer, TR33, Pt1000, 4-20 mA, M12x1, 50 mm - Riegler 148310
€100.42
Total price
Where semiconductor sensors run out of range, a Pt100 probe keeps delivering stable readings. The 1WU-Temp Pt100 3m covers -50 to +200 °C with an accuracy of ±(0.25 + 0.002 x |t|) °C and carries its converter right in the cable.
Benefits
- Pt100 accuracy: ±(0.25 + 0.002 x |t|) °C with 0.1 °C resolution.
- Built-in converter: conversion to 1-Wire UNI happens in the cable, so the RJ11 plug goes straight into the monitoring unit.
- IP67 probe: ready for outdoor areas, wet rooms and refrigeration units.
- Calibration ready: 8 calibration points according to the manufacturer.
- Bus powered: 5 V via RJ11 at 2 mA.
Technical data
| Measured value | Temperature |
|---|---|
| Measuring range | -50 to +200 °C |
| Accuracy | ±(0.25 + 0.002 x |t|) °C |
| Resolution | 0.1 °C |
| Sensing element | Pt100 |
| Calibration points | 8 |
| Interface | 1-Wire UNI, RJ11 plug |
| Cable | 3 m, converter in the cable |
| Power supply | 5 V via RJ11 (1-Wire bus) |
| Consumption | 2 mA |
| Galvanic isolation | No |
| Operating conditions | -50 to +200 °C, 10 to 100 % RH |
| Storage conditions | +5 to +40 °C, 5 to 85 % RH |
| Protection | IP67 (probe) |
| Mounting | Wall |
| Warranty | 24 months |
| Manufacturer part number | 600907 |
Applications
- Outdoor temperature monitoring
- Temperature measurement in the pharmaceutical and food industry
- Fridges and freezers
- Agriculture
Scope of delivery
- 1WU-Temp Pt100 3m temperature sensor with Pt100 probe
- 3 m cable with integrated converter and RJ11 plug
Compatibility
- Connects as a sensor to a 1-Wire UNI RJ11 port, compatible with all HW group products according to the manufacturer
| Weight | 0.100000 |
|---|---|
| Manufacturer | HW group |
| Hersteller-Nr | 600907 |
| Zolltarifnummer | 90259090 |
| GPSR Herstellerdaten | HW group s.r.o., Rumunská 26, CZ-120 00 Praha 2, www.hw-group.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Czechia |
| Warranty | 2 years |
| Interface | 1-Wire |
| Protection rating | IP67 |
