Power presence detector Power Detector 110-230 V AC, EU plug Type C, relay output for DI - HW group 600667

Checking whether a circuit or a UPS input still has mains power does not require an electrician: the Power Detector simply plugs into the socket. Its normally open contact reports 110-230 V to any digital input and handles up to 50 V and 130 mA.

Benefits

• No installation: plug-in housing with EU plug, straight into the socket.
• Galvanically isolated: NO relay output rated 50 V / 130 mA, max. 10 Ohm when closed.
• Any two-wire cable: connect to the monitoring unit with any two-core cable.
• Low consumption: 3 mA at 230 V.
• Widely compatible: works with digital inputs on Poseidon2, Damocles2, STE2 and HWg-Ares.

Applications

• Monitoring the charging voltage at a UPS input
• Power failure alarms in server rooms, plant rooms and distribution boards
• Checking individual circuits, such as those feeding cooling and air conditioning

Compatibility

• Digital input (DI) of all HW group devices according to the manufacturer
• Poseidon2 3266, 3268, 3468, 4002
• Damocles2 1208, MINI, 2404
• STE2, I/O Controller, HWg-Ares
