LTE monitoring unit Ares 12 LTE G starter set with temperature sensor, power adapter and antenna, battery - HW group 600827

Monitoring plant rooms, cooling systems or remote sites that have no network connection calls for a unit that reports on its own over the mobile network. The Ares 12 LTE G reads up to 14 sensor values via 1-Wire UNI plus 2 digital inputs and raises alarms over LTE even during a power cut, with battery backup for up to 24 hours.

Benefits

• No LAN needed: data goes over LTE and GSM/GPRS to the SensDesk portal using HWg-Push.
• Ready to deploy: temperature sensor with 3 m IP67 cable, power adapter and external antenna are part of the kit.
• Alerts on threshold violations or input changes to up to 5 e-mail recipients and 5 phone numbers (SMS and call).
• Rides through outages with a 1300 mAh Li-Ion battery for up to 24 hours.
• 4 MB data logger for more than 250,000 records, and the 32-bit pulse counters keep their values without power.
• Firmware over the air (FOTA) and USB setup without extra software make large rollouts easier.

Technical data

Applications

• Remote plant rooms and distribution cabinets without LAN access
• Cooling systems, cold rooms and storage for food or materials
• Monitoring of machines and their surroundings
• Mobile and outdoor installations within mobile coverage

Scope of delivery

• Ares 12 LTE G (global version)
• Power adapter with US, EU and UK plugs
• Temperature sensor with 3 m cable, IP67
• External antenna

Compatibility

• HW group 1-Wire UNI sensors
• Relay Output 1-Wire UNI for external switching outputs
• SensDesk portal for dashboards, history and remote configuration
