Double-acting compact cylinder Ø 80 mm stroke 86 mm ADN-80-86-A-P-A-12K2-"M20X1,5"K5-37K8-S1 - Festo 556119

With an 86 mm stroke and a Ø 80 mm piston, the ADN compact cylinder ADN-80-86-A-P-A-12K2-"M20X1,5"K5-37K8-S1 covers short linear movements. The letter A after the cushioning code in type ADN-80-86-A-P-A-12K2-"M20X1,5"K5-37K8-S1 stands for position detection via proximity switches. Being double-acting, the Ø 80 mm piston is driven by compressed air in both directions.

Benefits at a glance

• Piston Ø 80 mm, stroke 86 mm
• Elastic end-position cushioning P at both ends
• Piston rod with male thread
• Position detection via proximity switches
• Double-acting: force in both directions
• Weight 2.1 kg

Use

The ADN-80-86-A-P-A-12K2-"M20X1,5"K5-37K8-S1 handles pushing, lifting and ejecting movements over 86 mm in assembly systems, packaging machines and feeding equipment.
