Single-phase MID energy meter for direct connection up to 100 A with a Modbus RTU output. It covers heavily loaded 230 V feeds that exceed the 45 A model. Used in sub-distribution boards, on rack feeds and cooling units.
Single-phase energy meter PRO2-Mod, direct 0.25-100 A, 230 V, Modbus RTU, MID, 36 mm DIN rail - HW group 600858
HW GROUP
Original product
Net price (excl. VAT)
€85.90
Item
HWG-600858
Manufacturer no.
600858
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.600858
Country of originNetherlands
Customs tariff number90283019
ConditionNew
Artikel
HWG-600858
Frequently Bought Together
Heavily loaded single-phase feeds can be metered up to 100 A without current transformers. The PRO2-Mod takes 36 mm of DIN rail, carries MID approval and reports energy data via Modbus RTU.
Benefits
- High direct current: up to 100 A with no external CTs.
- Billing grade: MID approved under Directive 2014/32/EU.
- Accurate: accuracy class 1 (B) for active energy.
- Digital readout: Modbus RTU for building management and monitoring.
- Local display: the LCD shows voltage, current, active, reactive and apparent power, frequency and power factor.
Technical data
| Measurement | direct, single-phase |
|---|---|
| Mains | 1x230 V |
| Current range | 0.25-100 A |
| Accuracy class active energy | 1 (B) |
| Approval | MID (Directive 2014/32/EU) |
| Interface | Modbus RTU |
| Display | LCD |
| Galvanic isolation | Yes |
| Power supply | 230 V |
| Consumption | 2 mA |
| Connection | screw terminals |
| Mounting | DIN rail |
| Dimensions (W x H x D) | 36 x 90 x 63 mm |
| Warranty | 24 months |
| Manufacturer part number | 600858 |
Applications
- Single-phase main feeds of racks and server rooms
- Cooling units, pumps and CDUs with single-phase supply
- Sub-metering and cost allocation in commercial and industrial sites
- Integration into Modbus RTU building management systems
Scope of delivery
- PRO2-Mod single-phase meter with Modbus RTU output
| Weight | 0.160000 |
|---|---|
| Manufacturer | HW group |
| Hersteller-Nr | 600858 |
| Zolltarifnummer | 90283019 |
| GPSR Herstellerdaten | HW group s.r.o., Rumunská 26, CZ-120 00 Praha 2, www.hw-group.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Netherlands |
| Warranty | 2 years |
| Digital display | Ja |
| Interface | RS-485 |
| Operating voltage | 230 V AC |
