Solenoid valve 5/2-way or 3/2-way, convertible G1/4 VSNC-FC-M52-MD-G14-FN-1A1+G - Festo 8078398
The VSNC-FC-M52-MD-G14-FN-1A1+G switches compressed air as a 5/2-way valve convertible to 3/2-way and reaches 1250 l/min standard nominal flow rate. Ratings: 2.5 to 8 bar operating pressure, G1/4 port and 32 mm width. Mounts directly on the quarter-turn actuator via the NAMUR interface.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The solenoid valve VSNC-FC-M52-MD-G14-FN-1A1+G works as a 5/2-way valve convertible to 3/2-way and reaches 1250 l/min standard nominal flow rate at 2.5 to 8 bar operating pressure. In addition, the VSNC-FC-M52-MD-G14-FN-1A1+G offers G1/4 port, 32 mm width and 24 V DC operating voltage.
Benefits
- Flow: 1250 l/min standard nominal flow rate at only 32 mm width
- Pressure range: 2.5 to 8 bar
- Switching times: 35 ms on, 92 ms off
- Rugged: IP65/IP67 protection, corrosion resistance class 2
- Interface: NAMUR connection pattern to VDI/VDE 3845
- Temperature: -20 to 60 °C ambient
Applications
Thanks to the NAMUR connection pattern, the VSNC-FC-M52-MD-G14-FN-1A1+G mounts directly on pneumatic quarter-turn actuators without tubing between valve and actuator. Mounting: with through-hole. Operating medium for the VSNC-FC-M52-MD-G14-FN-1A1+G: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required).
Technical data
| Type | VSNC-FC-M52-MD-G14-FN-1A1+G |
|---|---|
| Festo part number | 8078398 |
| Valve function | 5/2-way or 3/2-way, convertible |
| Type of actuation | electrical |
| Width | 32 mm |
| Standard nominal flow rate | 1250 l/min |
| pneumatic working port | connection pattern to NAMUR |
| Operating voltage | 24 V DC |
| Operating pressure | 2.5 to 8 bar |
| Design | piston gate valve |
| Reset method | mechanical spring |
| Certificate issuing authority | DNVGL-TAA000011J |
| Degree of protection | IP65, IP67, with plug socket, to IEC 60529 |
| Exhaust-air function | can be throttled |
| Sealing principle | soft |
| Mounting position | any |
| Conforms to standard | VDI/VDE 3845 (NAMUR) |
| Manual override | detenting, non-detenting |
| Type of piloting | piloted |
| Pilot air supply | internal |
| Flow direction | non-reversible |
| Overlap | positive overlap |
| Signal status display | with accessories |
| b value | 0.4 |
| C value | 5.2 l/sbar |
| Standard nominal flow rate, exhaust return 4 to 3 | 110 l/min |
| Switching time off | 92 ms |
| Switching time on | 35 ms |
| Duty cycle | 100% |
| Coil characteristics | 24 V DC: 0.7 W |
| Permissible voltage fluctuations | ± 10 % |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | -20 to 60 °C |
| Ambient temperature | -20 to 60 °C |
| Product weight | 415 g |
| Electrical connection | to EN 175301-803 |
| Type of mounting | with through-hole |
| Breather connection | not ducted |
| Pneumatic connection, port 1 | G1/4 |
| Pneumatic connection, port 2 | connection pattern to NAMUR |
| Pneumatic connection, port 3 | G1/4 |
| Pneumatic connection, port 4 | connection pattern to NAMUR |
| Pneumatic connection, port 5 | G1/4 |
| Note on materials | RoHS compliant |
| Material seals | NBR |
| Material housing | wrought aluminium alloy |
| Material screws | galvanised steel |
| Weight (shipping) | 0.5 kg |
| Weight | 0.5 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VSNC-FC-M52-MD-G14-FN-1A1+G |
| EAN | 4052568446567 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
| Seal material | NBR |
| Medium | Compressed air |
| Function | 5/2 or 3/2 convertible |
| Flow rate [l/min] | 1250 |
| Actuation type | Electrical |
| Norm | NAMUR, VDI/VDE 3845 |
| Series | VSNC |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | G1/4 |
| Temperaturbereich | -20-60 °C |
