S2V series valve terminal, 6 stations 5/2-way, IO-Link, G 1/8 top ports - E.MC

Instead of wiring each solenoid separately, the terminal joins the IO-Link network as a single node. It carries 6 single-solenoid 5/2-way valves with about 700 l/min per station and keeps the overall length to 168.5 mm.

Advantages

• Diagnostics for short circuit, wire break, reverse polarity and under- or overvoltage, with a configurable safe output state on bus failure.
• G 1/8 outlets directly on the valves, easy to reach from above, 16 mm pitch.
• Reconfigurable: each station takes a single or double solenoid 5/2-way valve, a 5/3-way valve, a 2x 3/2-way valve or a blanking plate.
• Low heat load in the cabinet at 0.8 W per solenoid, with an LED for every switching state.
• Mounts on a DIN rail or with screws and runs on filtered air without a lubricator.

Applications

• Compact assemblies such as grippers, clamping or lifting units with up to 6 double-acting cylinders.
• Machines with an IO-Link master, where the terminal connects to a class B port via an M12 plug.
• Open DIN rail installation where hoses are plugged in and checked from above.
