Manifold sub-base valve accessory VABV-S2-1S-N38-T2 - Festo 542460

Festo ✓ Original product Brand new

The manifold sub-base VABV-S2-1S-N38-T2 from Festo holds the valves and distributes supply and exhaust air via continuous ducts. Key values: working ports 2 and 4 3/8 NPT, plate made of die-cast aluminium and corrosion resistance class CRC 0.

Net
€67.91
excl. VAT
Item FES-542460
Manufacturer no. VABV-S2-1S-N38-T2
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The manifold sub-base VABV-S2-1S-N38-T2 holds the valves and distributes supply and exhaust air via continuous ducts. Key values: working ports 2 and 4 3/8 NPT, plate made of die-cast aluminium and corrosion resistance class CRC 0.

Benefits at a glance

  • Working ports 2 and 4 3/8 NPT
  • Plate made of die-cast aluminium
  • Corrosion resistance class CRC 0, for environments without corrosion stress
  • PWIS conformity VDMA24364-B1/B2-L

Fields of application

A typical use of VABV-S2-1S-N38-T2 is building compact valve terminals in machine and plant engineering. VABV-S2-1S-N38-T2 creates a compact valve group with little tubing and fitting effort.

Technical data

Order codeVABV-S2-1S-N38-T2
Festo part number542460
CE mark (see declaration of conformity)In accordance with EU Directive on Simple Pressure Vessels
UKCA marking (see declaration of conformity)To UK regulations for electrical equipment
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Product weight340 g
Pneumatic connection, port 23/8 NPT
Pneumatic connection, port 43/8 NPT
Note on materialsRoHS compliant
Material plateDie-cast aluminium
Weight0.55 kg
ManufacturerFesto
Hersteller-NrVABV-S2-1S-N38-T2
EAN4052568347611
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialDie-cast aluminium
SeriesVABV
