Plastic tubing PE 16 x 12 mm red PLN-16X2-RT - Festo 558222

Festo ✓ Original product Brand new

Polyethylene tubing 16 x 12 mm for push-in fittings with 16 mm outside diameter. Operating pressure -0.95 to 14 bar, bending radius from 55 mm and ambient -30 to 80 °C. Suitable for water as well as compressed air.

Net
€8.27
excl. VAT
Item FES-558222
Manufacturer no. PLN-16X2-RT
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The PLN-16X2-RT is a plastic tubing in polyethylene with 16 mm outside diameter.

Benefits

  • Operating pressure -0.95 to 14 bar (temperature-dependent)
  • Minimum bending radius 55 mm, flow-relevant 95 mm
  • Ambient temperature -30 to 80 °C
  • Approval TÜV

Applications

Permitted media: compressed air to ISO 8573-1:2010 [7:-:-], water.

Technical data

FeatureValue
TypePLN-16X2-RT
Festo part number558222
Outside diameter16 mm
Flow-relevant bending radius95 mm
Inside diameter12 mm
Minimum bending radius55 mm
Temperature-dependent operating pressure-0.95 to 14 bar
ApprovalTÜV
Certificate issuing authorityB 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free)
LABS (PWIS) conformityVDMA24364-B2-L
Cleanroom suitability, measured according to ISO 14644-14Element installed statically, no meaningful evaluation possible according to ISO 14644-1
Suitable for use with foodSee supplementary material information
Ambient temperature-30 to 80 °C
Product weight according to length0.082 kg/m
ColourRed
Note on materialsRoHS compliant
Weight0.1 kg
ManufacturerFesto
Hersteller-NrPLN-16X2-RT
EAN4052568053956
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farberot
MaterialPolyethylene
MediumCompressed air, water
Schlauchdurchmesser (außen) [mm]16
Schlauchdurchmesser (außen x innen) [mm]16 x 12
Schlauchdurchmesser (innen) [mm]12
min. Biegeradius [mm]55
Betriebsdruck max [bar]14
Temperaturbereich-30-80 °C
