Spiral plastic tubing PA12 6.3 x 4.7 mm working length 15 m blue PPS-4-15-1/4-BL - Festo 19799

Festo ✓ Original product Brand new

The spiral tubing PPS-4-15-1/4-BL extends to a working length of 15 m and retracts to 0.67 m afterwards. Operating pressure -0.95 to 21.2 bar and ambient -30 to 80 °C.

Net
€120.71
excl. VAT
Item FES-19799
Manufacturer no. PPS-4-15-1/4-BL
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The spiral plastic tubing PPS-4-15-1/4-BL supplies moving consumers over a working length of 15 m and returns to its starting position by itself after extension. Connection: Male thread G1/4.

Benefits

  • Operating pressure -0.95 to 21.2 bar (temperature-dependent)
  • Working length 15 m with 0.67 m block length and 90 turns
  • Ambient temperature -30 to 80 °C

Applications

Operating medium compressed air to ISO 8573-1:2010 [7:-:-]. Typical on hand tools and blow guns.

Technical data

FeatureValue
TypePPS-4-15-1/4-BL
Festo part number19799
Working length15 m
Outside diameter6.3 mm
Block length0.67 m
Inside diameter4.7 mm
Winding diameter75 mm
Number of turns90
Temperature-dependent operating pressure-0.95 to 21.2 bar
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Corrosion resistance class CRC1 - low corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Ambient temperature-30 to 80 °C
Nominal torque11 Nm
Tolerance for nominal tightening torque± 20 %
Pneumatic connection, port 1Male thread G1/4
Pneumatic connection, port 2Male thread G1/4
ColourBlue
Material connecting threadbrass
Note on materialsRoHS compliant
Material buckling protectionSteel, Galvanised
Material tubingPA12-P
Weight (price list)0.34 kg
Weight0.34 kg
ManufacturerFesto
Hersteller-NrPPS-4-15-1/4-BL
EAN4052568113513
Zolltarifnummer39173300
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbeblau
MaterialPA 12
MediumCompressed air
Schlauchdurchmesser (außen) [mm]6,3
Schlauchdurchmesser (außen x innen) [mm]6,3 x 4,7
Schlauchdurchmesser (innen) [mm]4,7
Betriebsdruck max [bar]21
Temperaturbereich-30-80 °C
