Plastic tubing PE 12 x 8.4 mm blue PLN-12X1,75-BL - Festo 558209
Polyethylene tubing 12 x 8.4 mm for push-in fittings with 12 mm outside diameter. Operating pressure -0.95 to 14 bar, bending radius from 23 mm and ambient -30 to 80 °C. Suitable for water as well as compressed air.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The plastic tubing PLN-12X1,75-BL carries compressed air and water between valves, cylinders and service units. Connection: for push-in connector outside diameter of 12 mm.
Benefits
- Operating pressure -0.95 to 14 bar (temperature-dependent)
- Minimum bending radius 23 mm, flow-relevant 65 mm
- Ambient temperature -30 to 80 °C
- Approval TÜV
Applications
Operating medium compressed air to ISO 8573-1:2010 [7:-:-], water.
Technical data
| Feature | Value |
|---|---|
| Type | PLN-12X1,75-BL |
| Festo part number | 558209 |
| Outside diameter | 12 mm |
| Flow-relevant bending radius | 65 mm |
| Inside diameter | 8.4 mm |
| Minimum bending radius | 23 mm |
| Temperature-dependent operating pressure | -0.95 to 14 bar |
| Approval | TÜV |
| Certificate issuing authority | B 013277 0527 00 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free) |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -30 to 80 °C |
| Product weight according to length | 0.054 kg/m |
| Pneumatic connection | For push-in connector outside diameter of 12 mm |
| Colour | Blue |
| Note on materials | RoHS compliant |
| Weight | 0.065 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PLN-12X1,75-BL |
| EAN | 4052568053826 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | blau |
| Material | Polyethylene |
| Medium | Compressed air, water |
| Schlauchdurchmesser (außen) [mm] | 12 |
| Schlauchdurchmesser (außen x innen) [mm] | 12 x 8,4 |
| Schlauchdurchmesser (innen) [mm] | 8,4 |
| min. Biegeradius [mm] | 23 |
| Betriebsdruck max [bar] | 14 |
| Temperaturbereich | -30-80 °C |
