Compressed Air Preparation

Accessories for Compressed Air Preparation

Accessories for Festo compressed air preparation comprise the parts used to mount, join and connect service units. MS-WP, MS-WPB, MS-WPE, MS-WPM and MS-WR mounting brackets hold units and combinations on the machine or wall, MS-MV and MS-AMV module connectors join the individual units of an assembly.

Connecting plates and MS-AG connecting plate kits provide the thread on the unit, from G 1/8 to G 2 and NPT 1/8 to NPT 1 1/2. The range also includes LRVS regulator locks and padlocks, HR mounting brackets and threaded bolts for the D series in Mini, Midi and Maxi, as well as service kits and blow nozzles for PDAD adsorption dryers.

  • 175 items
  • 1 manufacturer
  • Net prices plus VAT
View as Grid view List view

Items 1-24 of 175

Set Descending Direction
per page
  1. Mounting bracket for MS4 series, pOM, High-alloy stainless steel MS4-WP-F1A - Festo 8176694
    €21.86
Page

Buying guide

How to choose Accessories for Compressed Air Preparation

What matters when choosing: properties, comparison and typical applications.

Selection criteria

CriterionOptionsWhat to look for
Partmounting bracket, module connector, connecting plate, regulator lock, threaded boltMountings and connectors must match the series, MS and D cannot be combined with each other.
Series and sizeMS4, MS6, MS9, MS12, D series Mini, Midi, MaxiThe size is part of the type code, for example MS6-WPB or HR-D-MIDI.
PortG 1/8 to G 2, NPT 1/8 to NPT 1 1/2The connecting plate defines the thread, independent of the unit.
Lockingregulator lock, LRVS padlockPrevents unauthorised adjustment of the set pressure.

Frequently asked questions

Why do I need a connecting plate?
MS series units have no fixed threads. The connecting plate provides the thread at the inlet and outlet of the unit, so you choose G or NPT and the size to suit the line.
How do I join two service units?
With a module connector of the matching size. It holds the units together and seals the joint, mounting brackets can be attached to the connector.
What does a regulator lock protect?
It blocks the regulator knob so that the set pressure cannot be changed without authorisation. The padlock locks the device.
