Standards-based cylinder, double-acting, Ø 12 mm, stroke 136 mm DSNU-12-136-P-A - Festo 556371

With its compact round design the DSNU-12-136-P-A delivers 136 mm of stroke and reaches 67.9 N on advance at 6 bar with a piston Ø of 12 mm and 50.9 N on return. The end positions can be sensed with proximity switches.

Benefits

• Piston Ø 12 mm and stroke 136 mm, defined by the order code DSNU-12-136-P-A
• Theoretical force at 6 bar: 67.9 N advance, 50.9 N return
• Elastic cushioning rings at both ends (P), permissible impact energy 0.07 J
• Cylinder barrel and piston rod in high-alloy stainless steel
• Air connection M5, piston rod thread M6
• Prepared for proximity switches to sense the end positions (code A in the type)

Applications

The DSNU-12-136-P-A suits stopping, sorting and feeding tasks where 136 mm stroke and a piston Ø of 12 mm are sufficient. The M6 piston rod thread on the DSNU-12-136-P-A takes the matching rod-end accessories. For replacement please compare the type DSNU-12-136-P-A with the installed cylinder.
