Shunt with a matched converter that measures DC current up to 30 A in both directions. It plugs into a 1-Wire UNI RJ11 port and detects overload as well as charge and discharge current. The finer-resolution option for smaller 12, 24 and 48 V DC loads.
DC current sensor 30A DC Current probe 1W-UNI, shunt 0-30 A, bidirectional, up to 60 V, 1-Wire UNI - HW group 600677
HW GROUP
Original product
Net price (excl. VAT)
€315.70
Item
HWG-600677
Manufacturer no.
600677
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.600677
Country of originCzechia
Customs tariff number90269000
ConditionNew
Artikel
HWG-600677
Frequently Bought Together
Smaller DC loads and battery circuits need a shunt that still resolves low currents cleanly. The 30A DC Current probe 1W-UNI measures up to 30 A in both directions with 2 % accuracy and 0.1 A resolution, reporting via 1-Wire UNI to Poseidon2 or Ares.
Benefits
- Direction aware: charging reads positive, discharging negative.
- Sized for smaller loads: 0-30 A DC with 0.1 A resolution.
- Matched shunt: 2 mOhm, 60 mV drop at 30 A.
- Isolated: the 1-Wire UNI bus is electrically isolated from the measured circuit.
- Bus powered: 5 V via RJ11 at 3 mA, no power supply needed.
Technical data
| Measured value | DC current, bidirectional |
|---|---|
| Measuring range | 0-30 A DC |
| Accuracy | 2 % |
| Resolution | 0.1 A |
| Shunt | 2 mOhm, 60 mV at 30 A |
| Circuit voltage | max. 60 V |
| Shunt to converter cable | 1 m, fixed length |
| Calibration points | 8 |
| Interface | 1-Wire UNI, 2x RJ11 for daisy-chaining |
| Sensors per active port | max. 2 |
| Galvanic isolation | Yes |
| Power supply | 5 V via RJ11 (1-Wire bus) |
| Consumption | 3 mA |
| Operating conditions | 0 to +40 °C, 0 to 80 % RH |
| Storage conditions | -10 to +60 °C, 0 to 80 % RH |
| Converter dimensions (W x H x D) | 79 x 68 x 30 mm |
| Protection | IP23 |
| Mounting | DIN rail, desktop, indoor use only |
| Warranty | 24 months |
| Manufacturer part number | 600677 |
Applications
- 48 V DC supply of individual racks and network equipment
- Battery circuits of smaller UPS systems
- 12 V and 24 V DC systems in telecom and railway technology
- Early warning of overload and current direction changes
Scope of delivery
- DC current sensor 0-30 A, consisting of shunt and matched 1-Wire UNI converter
- Shunt and converter are calibrated as a pair and cannot be swapped
Compatibility
- Connects to 1-Wire UNI RJ11 ports on Poseidon2 and Ares
- For currents up to 100 A, choose the 100A DC Current probe 1W-UNI (600678)
