Rod clevis female thread M4 ISO 8140 high-alloy steel CRSG-M4 - Festo 8165295
The rod clevis CRSG-M4 attaches the piston rod to the mating part via a pin so that it can pivot, female thread M4. Designed to ISO 8140 and DIN 71752. Clevis made of high-alloy steel, CRC 1 (low corrosion stress). Ambient temperature -40 to 150 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Where the piston rod has to follow a swivel movement, the rod clevis CRSG-M4 provides the pivoting connection, female thread M4, CRC 1 (low corrosion stress).
Benefits at a glance
- Female thread M4
- Standard: ISO 8140 and DIN 71752
- Clevis and bolt made of high-alloy steel
- Ambient temperature -40 to 150 °C
- Corrosion resistance class 1 - low corrosion stress
- Materials: RoHS compliant
Typical applications
The CRSG-M4 is used on cylinders that move flaps, gates or lever mechanisms around a pivot point.
Technical data
| Order type | CRSG-M4 |
|---|---|
| Festo part number | 8165295 |
| Size | M4 |
| Mounting position | any |
| Based on standard | ISO 8140 |
| Conforms to standard | DIN 71752 |
| Threaded connection | female thread M4 |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| PWIS conformity (LABS) | VDMA24364-B2-L |
| Suitability for Li-ion battery production | metals with more than 5% copper, zinc or nickel by mass are excluded, except nickel in steels, electroless nickel-plated surfaces, printed circuit boards, cables, electrical connectors and coils |
| Ambient temperature | -40 to 150 °C |
| Product weight | 8 g |
| Material rod clevis | high-alloy steel |
| Note on materials | RoHS compliant |
| Material bolt | high-alloy steel |
| Material nut | high-alloy steel |
| Material retainer | high-alloy steel |
| Customs tariff number | 73181900 |
| Weight | 0.009 kg |
| Manufacturer | Festo |
| Hersteller-Nr | CRSG-M4 |
| EAN | 4052568605926 |
| Zolltarifnummer | 73181900 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | M4 |
| Thread type | Internal thread |
| Norm | DIN 71752, ISO 8140 |
| Series | CRSG |
| Temperaturbereich | -40-150 °C |
| Temperature (max.) | 150 |
