Thread adapter male thread G1 to female thread 1 NPT nominal width 21.4 mm AD-G1-1NPT-I - Festo 546546

Festo ✓ Original product Brand new

The thread adapter AD-G1-1NPT-I converts a G1 male port to a 1 NPT female thread and so bridges G and NPT threads. Operating pressure -0.95 to 10 bar, nominal width 21.4 mm. Housing made of zinc-plated steel, PVC seal, CRC 1 (low corrosion stress).

Net
€23.35
excl. VAT
Item FES-546546
Manufacturer no. AD-G1-1NPT-I
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo adapter AD-G1-1NPT-I has a male thread G1 on one side and a female thread 1 NPT on the other, nominal width 21.4 mm.

Benefits at a glance

  • Port 1: male thread G1, port 2: female thread 1 NPT
  • Max. tightening torque 90 Nm (port 1) and 35 Nm (port 2)
  • Operating pressure -0.95 to 10 bar over the full temperature range
  • Nominal width 21.4 mm
  • Usable at ambient temperatures of -10 to 60 °C
  • Corrosion resistance class 1 - low corrosion stress

Typical applications

The AD-G1-1NPT-I is typically used to connect NPT components to valves, service units or manifolds with G threads, and vice versa.

Technical data

Order typeAD-G1-1NPT-I
Festo part number546546
Nominal width21.4 mm
Operating pressure over full temperature range-0.95 to 10 bar
Corrosion resistance class CRC1 - low corrosion stress
PWIS conformity (LABS)VDMA24364-B1/B2-L
Ambient temperature-10 to 60 °C
Max. tightening torque port 190 Nm
Max. tightening torque port 235 Nm
Product weight212.68 g
Pneumatic port 1male thread G1
Pneumatic port 2female thread 1 NPT
Note on materialsRoHS compliant
Material sealsPVC
Material housingsteel, zinc-plated
Customs tariff number73079910
ManufacturerFesto
Hersteller-NrAD-G1-1NPT-I
EAN4052568354046
Zolltarifnummer73079910
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialGalvanised steel
Seal materialPVC
Thread typeExternal thread
Thread type 2Internal thread
SeriesAD
Pneumatic connectionG1 AG
Temperaturbereich-10-60 °C
Temperature (max.)60
