Rod clevis thread UNF5/16-24 ISO 8140 steel zinc-plated SG-UNF5/16"-24-B - Festo 546574
The rod clevis SG-UNF5/16"-24-B (thread UNF5/16-24) connects the piston rod to a lever, flap or bracket with a pivoting joint. Designed to ISO 8140. Clevis made of steel, zinc-plated, CRC 1 (low corrosion stress). Ambient temperature -40 to 150 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo rod clevis SG-UNF5/16"-24-B links the piston rod to a pivoting attachment, thread UNF5/16-24, designed to ISO 8140.
Benefits
- Thread UNF5/16-24
- Clevis and bolt made of steel, zinc-plated
- Standard: ISO 8140
- Ambient temperature -40 to 150 °C
- Corrosion resistance class 1 - low corrosion stress
- Materials: RoHS compliant
Use
Typical applications are flaps, levers, diverters and toggle linkages that the cylinder actuates via the SG-UNF5/16"-24-B.
Technical data
| Order type | SG-UNF5/16"-24-B |
|---|---|
| Festo part number | 546574 |
| Size | UNF5/16-24 |
| Based on standard | ISO 8140 |
| Corrosion resistance class CRC | 1 - low corrosion stress |
| PWIS conformity (LABS) | VDMA24364-B2-L |
| Ambient temperature | -40 to 150 °C |
| Product weight | 54.886 g |
| Note on materials | RoHS compliant |
| Material bolt | steel, zinc-plated |
| Material clevis | steel, zinc-plated |
| Material nut | steel, zinc-plated |
| Customs tariff number | 90330090 |
| Manufacturer | Festo |
| Hersteller-Nr | SG-UNF5/16"-24-B |
| EAN | 4052568354329 |
| Zolltarifnummer | 90330090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Galvanised steel |
| Norm | ISO 8140 |
| Series | SG |
| Temperaturbereich | -40-150 °C |
| Temperature (max.) | 150 |
