Compact cylinder double-acting Ø 63 mm stroke 110 mm ADN-63-110-A-P-A - Festo 609740

Where space in the stroke direction is short, the ADN-63-110-A-P-A fits in: double-acting compact cylinder, 63 mm piston, 110 mm stroke, 1870 N advance and 1750 N return force at 6 bar. The data below is derived from the type code ADN-63-110-A-P-A and Festo data of the ADN series with a 63 mm piston.

Benefits at a glance

• Force in both directions: theoretical 1870 N advance and 1750 N return at 6 bar
• Gentle end positions: elastic cushioning rings at both ends, impact energy up to 1.3 J
• Position sensing: prepared for proximity switches, port G1/8
• Flexible use: operating pressure 0.6 to 10 bar
• Attachment: piston rod with male thread, 63 mm piston

Applications

Pressing, joining and clamping larger workpieces are typical uses of the ADN-63-110-A-P-A with a 63 mm diameter. With 110 mm stroke it also handles longer pushing and feed travel.
