5/3-way solenoid valve, centre position pressurised, G 3/8", 115 V AC, 1600 l/min, 2 to 10 bar
This 5/3-way solenoid valve works with 115 V AC at connection G 3/8" and covers an operating pressure of 2 to 10 bar. The switching function is centre position pressurised. The materials are body and spool aluminium, seals NBR, pilot polyamide (glass fibre reinforced).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
This 5/3-way solenoid valve switches the air path electrically and needs no manual action at the machine. The connection is G 3/8" and control is by 115 V AC. The switching function is centre position pressurised. The operating pressure is stated as 2 to 10 bar. The materials are body and spool aluminium, seals NBR, pilot polyamide (glass fibre reinforced).
Advantages
- Temperature range of -10 to +60 °C, which covers use in the machine room as well as outdoors.
- Connection G 3/8" and exhaust G 3/8", so the piping follows the existing line network.
- Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.
- Media oiled and non-oiled, filtered compressed air, so no separate treatment is needed.
- Flow rate of 1600 l/min, so the connected actuator moves without the valve throttling it.
Applications
- Control of double-acting cylinders with an air demand up to 1600 l/min.
- Sequencing of pneumatic axes with connection G 3/8" in handling equipment.
- Installation in control cabinets with a supply of 115 V AC.
- Control of pneumatic flaps, gates and diverters in conveying equipment.
Technical data
| Feature | Value |
|---|---|
| Function | centre position pressurised |
| Control voltage | 115 V AC |
| Thread (3x) | G 3/8" |
| Exhaust thread (2x) | G 3/8" |
| Flow rate [l/min] | 1600 |
| Operating pressure [bar] | 2 to 10 |
| Power consumption (AC) [VA] | 4.1 |
| Material body and spool | aluminium |
| Material seals | NBR |
| Material pilot | polyamide (glass fibre reinforced) |
| Temperature range | -10 to +60 °C |
| Media | oiled and non-oiled, filtered compressed air |
| Switching time (at 5 bar) | below 40 ms |
| Control voltages | Standard: 24 V DC, 230 V AC, other voltages on request |
| Voltage tolerance | plus/minus 10 percent |
| Protection class | IP 65 |
| Manufacturer | YPC |
| Hersteller-Nr | SF5503 IPSC-A1 |
| EAN | 4050571623265 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Gewinde Abluft (2x) | G 3/8" |
| Leistungsaufnahme (AC) [VA] | 4,1 |
