Solenoid valve 5/2-way double solenoid 1/4 NPT ATEX VSNC-F-B52-D-N14-FN-1A1-EX4-A - Festo 577287
Solenoid valve VSNC-F-B52-D-N14-FN-1A1-EX4-A as a 5/2-way valve (double solenoid) with 1350 l/min standard nominal flow rate for controlling pneumatic actuators. Also 1.5 to 8 bar operating pressure, 1/4 NPT port and 32 mm width. NAMUR interface for quarter-turn actuators, no tubing needed.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With 1350 l/min standard nominal flow rate, the solenoid valve VSNC-F-B52-D-N14-FN-1A1-EX4-A switches as a 5/2-way valve (double solenoid) at 1.5 to 8 bar operating pressure. Further ratings: 1/4 NPT port, 32 mm width and 24 V DC operating voltage.
Benefits at a glance
- Flow: 1350 l/min standard nominal flow rate at only 32 mm width
- Pressure range: 1.5 to 8 bar
- Reversing time: 20 ms
- Explosion protection: ATEX category II 2G, II 2D
- Rugged: IP65 protection, corrosion resistance class 2
- Interface: NAMUR connection pattern to VDI/VDE 3845
Applications
The VSNC-F-B52-D-N14-FN-1A1-EX4-A mounts directly on quarter-turn actuators with NAMUR interface, so no tubing is needed between valve and actuator. For hazardous areas it is rated ATEX II 2G, II 2D. Mounting: with through-hole. Operating medium for the VSNC-F-B52-D-N14-FN-1A1-EX4-A: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required).
Technical data
| Type | VSNC-F-B52-D-N14-FN-1A1-EX4-A |
|---|---|
| Festo part number | 577287 |
| Valve function | 5/2-way, double solenoid |
| Type of actuation | electrical |
| Width | 32 mm |
| Standard nominal flow rate | 1350 l/min |
| pneumatic working port | connection pattern to NAMUR |
| Operating voltage | 24 V DC |
| Operating pressure | 1.5 to 8 bar |
| Design | piston gate valve |
| Explosion protection certification outside the EU | EPL Ga (IEC-EX) |
| Certificate issuing authority | DNVGL-TAA000011J |
| ATEX category gas | II 2G |
| ATEX category dust | II 2D |
| Explosion ignition protection type for gas | Ex ia IIC T6 Ga |
| Explosion ignition protection type for dust | Ex t IIIC T80°C Db |
| Explosion ambient temperature | -40°C ≤ Ta ≤ +50°C |
| Degree of protection | IP65, with plug socket, to IEC 60529 |
| Exhaust-air function | can be throttled |
| Sealing principle | soft |
| Mounting position | any |
| Conforms to standard | VDI/VDE 3845 (NAMUR) |
| Manual override | detenting, non-detenting |
| Type of piloting | piloted |
| Pilot air supply | internal |
| Flow direction | non-reversible |
| Overlap | positive overlap |
| Signal status display | with accessories |
| b value | 0.4 |
| C value | 5.6 l/sbar |
| Switching time reversal | 20 ms |
| Duty cycle | 100% |
| Max. input voltage Ui | 28 V |
| Max. input current Ii | 115 mA |
| Permissible voltage fluctuations | ± 10 % |
| Explosion protection | Zone 0 (IEC-EX), Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 21 (IEC-EX), Zone 22 (ATEX) |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Media temperature | -20 to 60 °C |
| Ambient temperature | -20 to 60 °C |
| Product weight | 685 g |
| Electrical connection | to EN 175301-803 |
| Type of mounting | with through-hole |
| Breather connection | not ducted |
| Pneumatic connection, port 1 | 1/4 NPT |
| Pneumatic connection, port 2 | connection pattern to NAMUR |
| Pneumatic connection, port 3 | 1/4 NPT |
| Pneumatic connection, port 4 | connection pattern to NAMUR |
| Pneumatic connection, port 5 | 1/4 NPT |
| Note on materials | RoHS compliant |
| Material seals | NBR |
| Material housing | wrought aluminium alloy |
| Material screws | galvanised steel |
| Weight (shipping) | 0.7 kg |
| Weight | 0.7 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VSNC-F-B52-D-N14-FN-1A1-EX4-A |
| EAN | 4052568262679 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | NPT 1/4 |
| Seal material | NBR |
| Medium | Compressed air |
| Function | 5/2 bistable |
| Flow rate [l/min] | 1350 |
| Actuation type | Electrical |
| Norm | NAMUR, VDI/VDE 3845 |
| Series | VSNC |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | NPT 1/4 |
| Protection rating | IP65 |
| Temperaturbereich | -20-60 °C |
