Electronics module for VMPA valve terminal, 1 input, 1 output, 1 valve position VMPA-FB-EMG-P5 - Festo 8111882
The electronics module VMPA-FB-EMG-P5 is a genuine Festo part for VMPA series valve terminals. The data sheet lists 1 input, 1 output and 1 valve position. It also offers 1 valve coil and reverse polarity protection. It is RoHS compliant.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The electronics module VMPA-FB-EMG-P5 is a genuine Festo part for VMPA series valve terminals. For system design, the relevant data are 1 input and 1 output.
Advantages
- 1 input
- 1 output
- Individual sub-base for 1 valve position
- Controls 1 valve coil
- Integrated reverse polarity protection
- Suitable for ambient temperatures of -5 to 50 °C
Application
VMPA-FB-EMG-P5 is needed for new builds as well as for modifying existing VMPA series valve terminals.
Technical data
| Type | VMPA-FB-EMG-P5 |
|---|---|
| Festo part number | 8111882 |
| Series | VMPA |
| Diagnosis | Undervoltage of valves, Fault in pilot pressure supply, Time measurement overflow |
| Max. number of valve positions | 1 |
| Max. number of valve coils | 1 |
| Parameterisation | Fail-safe per channel, Forcing per channel, Idle mode per channel, Monitoring |
| Reverse polarity protection | Yes |
| Additional functions | For soft-start valve |
| Operating voltage range DC electronics/sensors | 18 to 30 V |
| Operating voltage DC load voltage | 21.6 to 26.4 V |
| Internal current consumption, load voltage | 5.5 mA |
| Internal current consumption, operating voltage | 12 mA |
| Max. number of outputs | 1 |
| Max. number of inputs | 1 |
| Nominal pick-up current per solenoid coil | 60 mA to 30 ms |
| Nominal current with current reduction | 22 mA after 30 ms |
| Isolation channel - internal bus | Yes |
| Corrosion resistance class CRC | (installed) |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | -5 to 50 °C |
| Product weight | 20 g |
| Electrical control | Fieldbus |
| Material housing | POM |
| Note on materials | RoHS compliant |
| Weight | 0.031 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VMPA-FB-EMG-P5 |
| EAN | 4052568588694 |
| Zolltarifnummer | 85371098 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Temperature (max.) | 50 |
