S2V series valve terminal for bus module, 6 stations 5/2-way single solenoid, G 1/8 top ports - E.MC

This version of the S2V terminal is prepared for an E.MC bus module, which is not included. That leaves the protocol open, for example PROFINET, EtherCAT or IO-Link, to match the existing controller. The terminal carries 6 single-solenoid 5/2-way valves.

Advantages

• Standard power consumption of 0.8 W per solenoid at 24 V DC, insulation class F.
• Mounts on a DIN rail or with screws and runs on filtered air without a lubricator.
• Protocol left open: E.MC offers bus modules for PROFINET, EtherCAT, EtherNet/IP, DeviceNet, CC-Link, CANopen, PROFIBUS DP and IO-Link.
• G 1/8 outlets directly on the valves, easy to reach from above, 16 mm pitch.
• Reconfigurable: each station takes a single or double solenoid 5/2-way valve, a 5/3-way valve, a 2x 3/2-way valve or a blanking plate.

Applications

• Compact assemblies such as grippers, clamping or lifting units with up to 6 double-acting cylinders.
• Machine series that ship with different controllers and bus protocols depending on the customer.
• Open DIN rail installation where hoses are plugged in and checked from above.
