Mini elbow flow control valve with check function, exhaust air control (standard), M 5, tube 4 mm

This mini elbow flow control valve with check function sets the flow volume in a compressed air line. The version is exhaust air control (standard). The connection is M 5. The materials are body Nickel-plated brass / PBT, seal NBR, retaining claw stainless steel, cartridge ZnDC nickel-plated, release ring PBT. The operating pressure is stated as -0.95 to 1 bar.

Advantages

• Dimensions H 26.5, L 15.7, so the design stays slim at the cylinder.
• Version exhaust air control (standard), so the speed is limited on the correct side of the piston.
• Push-in connector for tube with 4 mm outside diameter, release works without tools through the release ring.
• Connection thread M 5 for screwing directly into the cylinder end cap.
• Materials body Nickel-plated brass / PBT, seal NBR, retaining claw stainless steel, cartridge ZnDC nickel-plated, release ring PBT, only silicone-free seals and lubricants are used during assembly.

Technical data

Applications

• Screwing directly into cylinder end caps with thread M 5.
• Avoiding the stick-slip effect on slow running actuators.
• Matching forward and return stroke in cycled handling devices.
• Production environments within the temperature range 0 to +60 °C.
