S2V series valve terminal, 6 stations 5/2-way, CC-Link, G 1/8 side ports on sub-base - E.MC

On machines with CC-Link control, this terminal drives up to 6 double-acting cylinders or other actuators. The bus module sits directly on the valve block, power and bus connect via M12 plugs, and each valve draws 0.8 W.

Advantages

• G 1/8 outlets on the sub-base: hoses stay connected when a valve is replaced.
• Reconfigurable: each station takes a single or double solenoid 5/2-way valve, a 5/3-way valve, a 2x 3/2-way valve or a blanking plate.
• Low heat load in the cabinet at 0.8 W per solenoid, with an LED for every switching state.
• Mounts on a DIN rail or with screws and runs on filtered air without a lubricator.
• CC-Link right on the valve block: bus via M12 plug and M12 socket, 5-pin, A-coded, power via M12, 5-pin, A-coded. The bus module draws less than 50 mA.

Applications

• Compact assemblies such as grippers, clamping or lifting units with up to 6 double-acting cylinders.
• Existing CC-Link installations that are extended with additional pneumatic axes.
• Installation in shallow housings or profile frames where hoses are routed out to the side.
