3/2-way solenoid valve, 3/2-way (NC), 2x G 1/4", 24 V DC, 1000 l/min, 1.5 to 8 bar, exhaust G 1/4"
This 3/2-way solenoid valve works with 24 V DC at connection 2x G 1/4" and covers an operating pressure of 1.5 to 8 bar. The switching function is 3/2-way (NC). The materials are body aluminium, seals NBR.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
This 3/2-way solenoid valve switches the air path electrically and needs no manual action at the machine. The connection is 2x G 1/4" and control is by 24 V DC. The switching function is 3/2-way (NC). The operating pressure is stated as 1.5 to 8 bar. The materials are body aluminium, seals NBR.
Advantages
- Temperature range of -5 to +50 °C, which covers use in the machine room as well as outdoors.
- Connection 2x G 1/4" and exhaust G 1/4", so the piping follows the existing line network.
- Control voltage tolerance plus/minus 10 percent, which makes short supply dips uncritical.
- Media oiled and non-oiled, filtered compressed air, so no separate treatment is needed.
- Flow rate of 1000 l/min, so the connected actuator moves without the valve throttling it.
Applications
- Control of double-acting cylinders with an air demand up to 1000 l/min.
- Sequencing of pneumatic axes with connection 2x G 1/4" in handling equipment.
- Installation in control cabinets with a supply of 24 V DC.
- Control of pneumatic flaps, gates and diverters in conveying equipment.
Technical data
| Feature | Value |
|---|---|
| Function | 3/2-way (NC) |
| Thread | 2x G 1/4" |
| Exhaust thread | G 1/4" |
| Flow rate [l/min] | 1000 |
| Material body | aluminium |
| Material seals | NBR |
| Temperature range | -5 to +50 °C |
| Operating pressure | 1.5 to 8 bar |
| Media | oiled and non-oiled, filtered compressed air |
| Switching time | below 22 ms |
| Control voltages | 24 V DC |
| Voltage tolerance | plus/minus 10 percent |
| Power consumption | 3.3 W |
| Protection class | IP 65 (connector size 1) |
| Weight | 0.19 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VUVS-LK25-M32C-14-B |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
