CC-Link fieldbus valve terminal, 10 x 5/2-way single solenoid, M7 side ports on the base, 24 V DC - E.MC

On an 11.5 mm pitch this manifold carries 10 valve positions, all fitted with spring-return 5/2-way valves. A CC-Link bus module comes fitted, so the controller addresses every solenoid over the network. The M7 ports are located on the side of the base plate, and supply and common exhaust are connected through G 1/8. Overall length is 187.5 mm.

Advantages

• CC-Link bus module with M12 plug and M12 socket, 5-pin, A-coded, module current draw below 50 mA.
• M7 ports with a nominal cross-section of 7 mm² (Cv 0.39), around 330 l/min flow per station.
• Response time of 15 ms or less at 5 bar and up to 5 switching cycles per second per valve.
• Only 0.8 W per solenoid at 24 V DC ±10 %, so 10 valves draw 8 W in total.
• Diagnostics report communication faults, short circuit, wire break, reverse polarity and under- or overvoltage, and the output state on bus failure can be parameterised.

Applications

• Systems on a CC-Link fieldbus where the valves sit close to the actuators and only the bus cable runs to the cabinet.
• Medium-bore cylinders that move briskly with 330 l/min per station.
• Assembly cells with cylinders, grippers and rotary actuators served jointly by 10 valve positions.
• Installation under low covers, since the tubes leave sideways from the base plate rather than upwards.

Conversion and extension

The valves can be swapped for individually available valves with one or two solenoids or for blanking plates. Stations are counted from the electrical connection.
