Terminal box with jump module for SF2000 valve terminal, 6 stations, 24 V DC, 25-pin D-Sub - YPC MCS221

Instead of wiring every solenoid coil separately, the SF2000 series valves plug onto the terminal box. The box with jump module has 6 stations, slides onto the manifold on a dovetail guide and connects through a 25-pin D-Sub plug.

Advantages

• LED status indicator and protective circuit at every station
• 24 V DC, voltage tolerance ±10 %, power consumption 2.5 W per station
• Dovetail guide for the 6-station manifold, valves simply plug on and are screwed down
• 6 stations on one 25-pin D-Sub connector, one multipole cable instead of single wires

Applications

• Compact valve groups with a few cylinders, for example on fixtures and handling modules
• Systems where the PLC is to control several valves through a single cable
• Retrofitting an existing valve terminal with a central electrical connection

Accessories and spare parts

On the pneumatic side, the terminal also needs the SF2000 series manifold with 6 positions. Every double solenoid or 5/3-way valve requires a connection plate for the second solenoid, and unused stations are closed with a blanking plate. Where vibration occurs, mounting plates secure the coils to the box. The multipole cable with D-Sub plug is available separately.
