This 3/2-way pneumatic valve controls compressed air through connection G 1/8". The switching function is Impulse valve. The materials are body and spool aluminium, seals NBR, pilot polyamide.
3/2-way pneumatic valve, Impulse valve, G 1/8", 500 l/min, nominal size 3.9 mm, 1.5 to 8 bar
E.MC
Original product
Net price (excl. VAT)
€57.62
Item
FL-313596
Manufacturer no.
RV 3212-06 A
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RV 3212-06 A
EAN4050571714765
Customs tariff number84812090
ConditionNew
Artikel
FL-313596
Frequently Bought Together
This 3/2-way pneumatic valve is pilot-operated and needs no electrical installation. The switching function is Impulse valve. The connection is G 1/8". The operating pressure is stated as 1.5 to 8 bar. The materials are body and spool aluminium, seals NBR, pilot polyamide.
Advantages
- Flow rate of 500 l/min, so the connected actuator moves without the valve throttling it.
- Switching function Impulse valve, so the rest position is clearly defined.
- Nominal size of 3.9 mm, which defines the usable cross section of the switching position.
- Operating pressure of 1.5 to 8 bar, which fixes the permissible working range.
- Materials body and spool aluminium, seals NBR, pilot polyamide, matched to the intended service.
Technical data
| Feature | Value |
|---|---|
| Function | Impulse valve |
| Thread G1 (2x) | G 1/8" |
| Exhaust thread G1 (1x) | G 1/8" |
| Pilot port thread G2 | 2x G 1/8" |
| Nominal diameter [mm] | 3.9 |
| Flow rate [l/min] | 500 |
| Dimensions [mm] | A 70.0, B 27, C 18, D 7.5, E 24.5, F 21, H1 3.2, H2 3.3, J 13, K 25.5, L 19, M 27, N 16, O 36, P 1.5, W 2 |
| Material body and spool | aluminium |
| Material seals | NBR |
| Material pilot | polyamide |
| Temperature range | -5 to +60 °C |
| Operating pressure | 1.5 to 8 bar |
| Pilot pressure | 2 to 8 bar |
| Media | oiled and non-oiled, filtered compressed air |
| Service life | min. 40 million switching cycles |
Applications
- Cycled feeding and clamping units in fixture building.
- Plants operated within the temperature range -5 to +60 °C.
- Replacement of a defective valve of the same type in existing machines.
- Control of double-acting cylinders with an air demand up to 500 l/min.
| Weight | 0.090000 |
|---|---|
| Manufacturer | E.MC |
| Hersteller-Nr | RV 3212-06 A |
| EAN | 4050571714765 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Function | Impulsventil |
| Flow rate [l/min] | 500 |
