Angle seat valve, pneumatic, G 2", brass, normally closed, standard, 0 - 4 bar

As a angle seat valve the article shuts off liquids, steam and gases in an inclined seat with a low pressure drop. The data state a working pressure range of 0 - 4 bar. The stated figures are connection G 2" and installation length 124 mm. Also stated are the normal position closed and the version standard.

Benefits

• Working pressure range 0 - 4 bar at connection G 2".
• Medium temperature -10 to +80 °C at an ambient temperature of -10 to +60 °C.
• Installation length 124 mm, valve body in brass.
• Control pressure 4 to 10 bar, 6 bar as the optimum, control port G 1/8 inch.
• Normal position closed in the standard version.

Applications

In cleaning and filling plants the valve of 124 mm installation length and the normal position closed sits in the line.

Standards and conformity

The control pressure is 4 to 10 bar, 6 bar as the optimum, and the control port is G 1/8 inch. The seat seal is made of PTFE.
