Silencer with plug nipple, Blue Series, plug nipple 10 mm, type 566.010 - Riegler 109940

Silencer 566.010 is plugged directly into a push-in port with its 10 mm plug nipple and reduces exhaust noise there. Type 566.010 is designed for compressed air with a working pressure from -0.95 bar to 10 bar, short term 15 bar and -20 to 80 °C.

Advantages

• Rated for positive pressure up to 10 bar (15 bar short term) and vacuum down to -0.95 bar
• Usable from -20 to 80 °C
• Made of plastic

Applications

Type 566.010 fits exhaust ports with a 10 mm push-in connection. Riegler lists these applications for type 566.010: compressed air systems, automotive, packaging industry and vacuum. Riegler recommends type 566.010 only for use with Blue Series push-in fittings, suitability for other series has to be checked by the user.
