Logic cover LFA25E-7X/CA40DQMG24FV for 2-way cartridge valves size 25, 420 bar, FKM seals - Bosch Rexroth R901125541

Name: Logic cover LFA25E-7X/CA40DQMG24FV for 2-way cartridge valves size 25, 420 bar, FKM seals - Bosch Rexroth R901125541
Brand: Bosch Rexroth
SKU: BRR-R901125541
Price: 1408.30 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Control cover for 2-way cartridge valves in size 25: LFA25E-7X/CA40DQMG24FV handles up to 420 bar and is rated for max. 700 l/min. Connection diagram ISO 7368, 24 V DC, FKM seals, weight 3.42 kg.

Net

€1,408.30

excl. VAT

Item BRR-R901125541

Manufacturer no. R901125541

Question about this item

Datasheet (PDF) User manual 4 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For 2-way cartridge valves in size 25, Bosch Rexroth supplies the logic cover LFA25E-7X/CA40DQMG24FV, rated up to 420 bar at max. 700 l/min. LFA25E-7X/CA40DQMG24FV sits as a control cover on the 2-way cartridge valve, closes the ISO 7368 cavity and enables flow A to B, B to A.

Benefits

420 bar: maximum operating pressure of LFA25E-7X/CA40DQMG24FV according to the manufacturer.
700 l/min flow: maximum throughput in size 25.
Connection diagram ISO 7368: LFA25E-7X/CA40DQMG24FV fits standardised cavities in size 25.
FKM seals: LFA25E-7X/CA40DQMG24FV is suitable for hydraulic fluid HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR.

Applications

For manifolds with 2-way cartridge valves to ISO 7368, as original equipment or spare part. Material number R901125541 identifies LFA25E-7X/CA40DQMG24FV unambiguously.

Technical data

Type	LFA25E-7X/CA40DQMG24FV
Material number	R901125541
Product type	Control cover for 2-way cartridge valves
Size	25
Operating pressure (max.)	420 bar
Max. flow	700 l/min
Type of connection	Subplate mounting
Connection diagram	ISO 7368
Number of ports	2
Number of switching positions	2
Spool symbol	A to B, B to A
Supply voltage	24 V DC
Seals	FKM
Hydraulic fluid	HL, HLP, HLPD, HVLP, HVLPD, HETG, HEES, HEPG, HFDU, HFDR
Weight	3.42 kg
Manufacturer	Bosch Rexroth
Hersteller-Nr	R901125541
GPSR Herstellerdaten	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Germany
Bauform	Plattenaufbau
Seal material	FKM
Flow rate [l/min]	700
Norm	DIN EN 61076-2-101, ISO 7368
Operating voltage	24 V DC
Betriebsdruck max [bar]	420
