Fitted with cover Z1, this size 100 logic element weighs exactly 50 kg. It switches up to 11500 l/min at operating pressure up to 450 bar and sits in a mounting cavity to ISO 7368-14-14-1-16. Two switching positions at two ports handle the passage A to B and B to A.
Logic Cartridge Valve LC2A100B40F-1X/Z1Q7G24F - Bosch Rexroth R901348273
BOSCH REXROTH
Original product
Net price (excl. VAT)
€7,342.92
Item
BRR-R901348273
Manufacturer no.
R901348273
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R901348273
Country of originGermany
ConditionNew
Artikel
BRR-R901348273
Frequently Bought Together
-
This Item:
€7,342.92
-
Logic Cover LFA32EM-7X/CD40DQMG24 - Bosch Rexroth R900959750
€1,576.24
-
Logic Cartridge Valve LC2A050B40F-1X/Z1Q7G24F - Bosch Rexroth R901409446
€2,559.68
Total price
In manifolds carrying several logic elements an unambiguous cover version matters most. The LC2A100B40F-1X with cover Z1 opens the path A to B and B to A for up to 11500 l/min, with 450 bar operating pressure permitted. Actuation is hydraulic and the pilot stage works on 24 V DC.
Benefits
- Flow rate up to 11500 l/min at size 100
- Operating pressure up to 450 bar, FKM seals
- Cover Z1, hydraulic actuation, 24 V DC pilot stage
- Mounting cavity to ISO 7368-14-14-1-16, two ports
- 50 kg weight, two switching positions
Technical data
| Connection diagram | ISO 7368-14-14-1-16 |
| Max. flow | 11500 l/min |
| Product family | LC2A |
| Type of connection | Cartridge valve |
| Supply voltage | 24 VDC |
| Number of switching positions | 2 |
| Hydraulic fluid | HL |
| Number of ports | 2 |
| Spool symbol | A to B, B to A |
| Operating pressure, max. | 450 bar |
| Size | 100 |
| Seals | FKM |
| Type of actuation | with hydraulic actuation |
| Weight | 50 kg |
Applications
Elements of this kind take over the duties of main and prefill valves in presses and rolling mills. They sit inside the manifold and switch large oil volumes over a short stroke. When replacing one, check cavity, cover version and seal material.
Manufacturer
Bosch Rexroth, material number R901348273. The type code LC2A100B40F-1X/Z1Q7G24F defines size, connection diagram and cover version without ambiguity.
| Norm | DIN EN 61076-2-101, ISO 7368 |
|---|---|
| Hersteller-Nr | R901348273 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 50.000000 |
| GPSR Herstellerdaten | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
