Plastic tubing PU 14 x 9.8 mm silver PUN-14X2-SI - Festo 570389

Festo ✓ Original product Brand new

Pneumatic tubing PUN-14X2-SI in polyurethane, OD 14 mm, ID 9.8 mm. Operating pressure -0.95 to 10 bar depending on temperature, -0.95 to 7 bar across the full temperature range, bending radius from 45 mm and ambient -35 to 60 °C. Suitable for energy chains.

Net
€5.56
excl. VAT
Item FES-570389
Manufacturer no. PUN-14X2-SI
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Plastic tubing in polyurethane for compressed air distribution, OD 14 mm, ID 9.8 mm. Connection: for push-in connector outer diameter of 14 mm.

Benefits

  • Operating pressure -0.95 to 10 bar (temperature-dependent)
  • -0.95 to 7 bar across the full temperature range
  • Minimum bending radius 45 mm, flow-relevant 84 mm
  • Suitable for energy chains, Shore hardness D 52 ± 3
  • Material fire behaviour UL94 HB
  • Ambient temperature -35 to 60 °C

Applications

Permitted media: compressed air to ISO 8573-1:2010 [7:-:-]. Suitable for energy chains and moving cable routing.

Technical data

FeatureValue
TypePUN-14X2-SI
Festo part number570389
Outside diameter14 mm
Flow-relevant bending radius84 mm
Inside diameter9.8 mm
Minimum bending radius45 mm
Tubing characteristicssuitable for energy chains
Operating pressure complete temperature range-0.95 to 7 bar
Temperature-dependent operating pressure-0.95 to 10 bar
ApprovalTÜV
Certificate issuing authorityB 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-]
Fire test materialUL94 HB
LABS (PWIS) conformityVDMA24364-B2-L
Ambient temperature-35 to 60 °C
Product weight according to length0.0949 kg/m
Pneumatic connectionFor push-in connector outer diameter of 14 mm
ColourSilver
Shore hardnessD 52 ± 3
Note on materialsRoHS compliant
Material tubingTPE-U(PU)
Weight0.11 kg
ManufacturerFesto
Hersteller-NrPUN-14X2-SI
EAN4052568058326
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbesilber
MaterialPolyurethan
MediumCompressed air
Schlauchdurchmesser (außen) [mm]14
Schlauchdurchmesser (außen x innen) [mm]14 x 9,8
Schlauchdurchmesser (innen) [mm]9,8
min. Biegeradius [mm]45
Betriebsdruck max [bar]10
Temperaturbereich-35-60 °C

Downloads
