Plastic tubing PTFE 10 x 7 mm natural PTFEN-10X1,5-NT - Festo 8061174
PTFE tubing 10 x 7 mm for push-in fittings with 10 mm outside diameter. Operating pressure -0.95 to 12 bar depending on temperature, -0.95 to 5 bar across the full temperature range, bending radius from 70 mm and ambient -20 to 150 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Plastic tubing in PTFE for compressed air distribution, OD 10 mm, ID 7 mm.
Benefits
- Operating pressure -0.95 to 12 bar (temperature-dependent)
- -0.95 to 5 bar across the full temperature range
- Minimum bending radius 70 mm, flow-relevant 100 mm
- Shore hardness D 55 ± 5
- Material fire behaviour UL94 V-0
- Ambient temperature -20 to 150 °C
Applications
Medium: compressed air to ISO 8573-1:2010 [7:-:-]. With a permissible ambient temperature up to 150 °C, it suits areas with high heat exposure, for example near ovens or hot tools.
Technical data
| Feature | Value |
|---|---|
| Type | PTFEN-10X1,5-NT |
| Festo part number | 8061174 |
| Outside diameter | 10 mm |
| Flow-relevant bending radius | 100 mm |
| Inside diameter | 7 mm |
| Minimum bending radius | 70 mm |
| Instructions on use | Tubing without printing |
| Operating pressure complete temperature range | -0.95 to 5 bar |
| Temperature-dependent operating pressure | -0.95 to 12 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Fire test material | UL94 V-0 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -20 to 150 °C |
| Product weight according to length | 0.086 kg/m |
| Colour | Natural |
| Shore hardness | D 55 ± 5 |
| Note on materials | RoHS compliant |
| Material tubing | PTFE |
| Weight | 0.09 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PTFEN-10X1,5-NT |
| EAN | 4052568290634 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | natur |
| Material | PTFE |
| Medium | Compressed air |
| Schlauchdurchmesser (außen) [mm] | 10 |
| Schlauchdurchmesser (außen x innen) [mm] | 10 x 7 |
| Schlauchdurchmesser (innen) [mm] | 7 |
| min. Biegeradius [mm] | 70 |
| Betriebsdruck max [bar] | 12 |
| Temperaturbereich | -20-150 °C |
