Plastic tubing PFA 12 x 8.4 mm natural PFAN-12X1,75-NT - Festo 197065
Pneumatic tubing PFAN-12X1,75-NT in PFA, OD 12 mm, ID 8.4 mm. Operating pressure -0.95 to 16 bar depending on temperature, -0.95 to 7 bar across the full temperature range, bending radius from 29 mm and ambient -20 to 150 °C. Also suitable for steam.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The plastic tubing PFAN-12X1,75-NT carries compressed air and water between valves, cylinders and service units. Connection: for push-in connector outside diameter of 12 mm.
Benefits
- Operating pressure -0.95 to 16 bar (temperature-dependent)
- -0.95 to 7 bar across the full temperature range
- Minimum bending radius 29 mm, flow-relevant 165 mm
- Shore hardness D 60 +5
- Material fire behaviour UL94 V-0
- Ambient temperature -20 to 150 °C
Applications
Medium: compressed air to ISO 8573-1:2010 [7:-:-], water and steam. Note on operating pressure: Water vapour: 0 - 0.15 MPa, 0 - 1.5 bar, 0 - 22 psi.
Technical data
| Feature | Value |
|---|---|
| Type | PFAN-12X1,75-NT |
| Festo part number | 197065 |
| Outside diameter | 12 mm |
| Flow-relevant bending radius | 165 mm |
| Inside diameter | 8.4 mm |
| Minimum bending radius | 29 mm |
| Instructions on use | Tubing without printing |
| Operating pressure complete temperature range | -0.95 to 7 bar |
| Temperature-dependent operating pressure | -0.95 to 16 bar |
| Note on operating pressure | Water vapour: 0 - 0.15 MPa, 0 - 1.5 bar, 0 - 22 psi |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free), Water vapour |
| Fire test material | UL94 V-0 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Cleanroom suitability, measured according to ISO 14644-14 | Element installed statically, no meaningful evaluation possible according to ISO 14644-1 |
| Note on temperature of medium | Steam: max 120 °C |
| Ambient temperature | -20 to 150 °C |
| Product weight according to length | 0.125 kg/m |
| Pneumatic connection | For push-in connector outside diameter of 12 mm |
| Colour | Natural |
| Shore hardness | D 60 +5 |
| Note on materials | RoHS compliant |
| Material tubing | PFA |
| Weight | 0.13 kg |
| Manufacturer | Festo |
| Hersteller-Nr | PFAN-12X1,75-NT |
| EAN | 4052568081812 |
| Zolltarifnummer | 39173200 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Farbe | natur |
| Material | PFA |
| Schlauchdurchmesser (außen) [mm] | 12 |
| Schlauchdurchmesser (außen x innen) [mm] | 12 x 8,4 |
| Schlauchdurchmesser (innen) [mm] | 8,4 |
| min. Biegeradius [mm] | 29 |
| Betriebsdruck max [bar] | 16 |
| Temperaturbereich | -20-150 °C |
