Plastic tubing PE 14 x 10 mm black PLN-14X2-SW - Festo 570423

Festo ✓ Original product Brand new

Pneumatic tubing PLN-14X2-SW in polyethylene, OD 14 mm, ID 10 mm. Operating pressure -0.95 to 14 bar, bending radius from 40 mm and ambient -30 to 80 °C. Suitable for water as well as compressed air.

Net
€6.49
excl. VAT
Item FES-570423
Manufacturer no. PLN-14X2-SW
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 14 mm outside diameter, the PLN-14X2-SW fits standard push-in fittings of this size. Connection: for push-in connector outer diameter of 14 mm.

Benefits

  • Operating pressure -0.95 to 14 bar (temperature-dependent)
  • Minimum bending radius 40 mm, flow-relevant 80 mm
  • Ambient temperature -30 to 80 °C
  • Approval TÜV

Applications

Operating medium compressed air to ISO 8573-1:2010 [7:-:-], water.

Technical data

FeatureValue
TypePLN-14X2-SW
Festo part number570423
Outside diameter14 mm
Flow-relevant bending radius80 mm
Inside diameter10 mm
Minimum bending radius40 mm
Temperature-dependent operating pressure-0.95 to 14 bar
ApprovalTÜV
Certificate issuing authorityB 013277 0527 00
Operating mediumCompressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free)
LABS (PWIS) conformityVDMA24364-B2-L
Cleanroom suitability, measured according to ISO 14644-14Element installed statically, no meaningful evaluation possible according to ISO 14644-1
Suitable for use with foodSee supplementary material information
Ambient temperature-30 to 80 °C
Product weight according to length0.07 kg/m
Pneumatic connectionFor push-in connector outer diameter of 14 mm
ColourBlack
Note on materialsRoHS compliant
Weight0.085 kg
ManufacturerFesto
Hersteller-NrPLN-14X2-SW
EAN4052568058364
Zolltarifnummer39173200
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Farbeschwarz
MaterialPolyethylene
MediumCompressed air, water
Schlauchdurchmesser (außen) [mm]14
Schlauchdurchmesser (außen x innen) [mm]14 x 10
Schlauchdurchmesser (innen) [mm]10
min. Biegeradius [mm]40
Betriebsdruck max [bar]14
Temperaturbereich-30-80 °C
