Vacuum generator with switch-on valve and vacuum switch Laval nozzle 0.45 mm vacuum 93 % OVEM-05-H-B-GO-CE-N-2N - Festo 583192
With a 0.45 mm Laval nozzle, the vacuum generator OVEM-05-H-B-GO-CE-N-2N reaches up to 93 % vacuum at a max. suction flow of 6 l/min. Integrated functions: vacuum switch and electric switch-on valve.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The vacuum generator OVEM-05-H-B-GO-CE-N-2N works with a 0.45 mm Laval nozzle. Ejector characteristic: high vacuum, Standard.
Benefits
- Vacuum up to 93 %
- Suction flow up to 6 l/min against atmosphere
- Electrics: connection M12x1, Plug
- Vacuum monitoring with integrated vacuum switch: switching output 2xNPN
Applications
The high vacuum suits dense, smooth workpieces such as sheet metal, glass or plastic panels.
Technical data
| Nominal size, Laval nozzle | 0.45 mm |
|---|---|
| Design | Modular |
| Ejector characteristic | High vacuum, Standard |
| Maximum vacuum | 93 % |
| Maximum suction flow rate against atmosphere | 6 l/min |
| Operating pressure | 2 to 8 bar |
| Valve function | Closed |
| Integrated function | Vacuum switch, Electric switch-on valve |
| Switching output | 2xNPN |
| Electrical connection | M12x1, Plug |
| Weight | 0.65 kg |
| Manufacturer | Festo |
| Hersteller-Nr | OVEM-05-H-B-GO-CE-N-2N |
| Zolltarifnummer | 84141089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Function | closed |
| Series | OVEM |
| Betriebsdruck max [bar] | 8 |
