T-shape vacuum generator Laval nozzle 1.4 mm 92.6 l/min VN-14-L-T4-PQ3-VQ3-RO2-B-CS - Festo 4591682
Up to 92.6 l/min suction flow against atmosphere comes from the 1.4 mm Laval nozzle of the vacuum generator VN-14-L-T4-PQ3-VQ3-RO2-B-CS. Connections are QS-8 for compressed air and QS-8 for vacuum, at 2 to 8 bar operating pressure.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The vacuum generator VN-14-L-T4-PQ3-VQ3-RO2-B-CS works with a 1.4 mm Laval nozzle. Ejector characteristic: standard, High suction volume.
Benefits
- Suction flow up to 92.6 l/min against atmosphere
Applications
Intended for applications with leakage, for example porous workpieces such as cardboard or wood, and for evacuating large volumes quickly.
Technical data
| Nominal size, Laval nozzle | 1.4 mm |
|---|---|
| Ejector characteristic | Standard, High suction volume |
| Design | T-shape |
| Maximum suction flow rate against atmosphere | 92.6 l/min |
| Operating pressure | 2 to 8 bar |
| Pneumatic connection, port 1 | QS-8 |
| Vacuum connection | QS-8 |
| Weight | 0.135 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VN-14-L-T4-PQ3-VQ3-RO2-B-CS |
| Zolltarifnummer | 84818079 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| For hose OD [mm] | 8 |
| Nominal size DN [mm] | 1,4 |
| Series | VN |
| Betriebsdruck max [bar] | 8 |
| Pneumatic connection | QS-8 |
