T-shape vacuum generator with switch-on valve and ejector pulse Laval nozzle 0.45 mm vacuum 89 % OVEL-5-H-10-P-VQ4-UC-C-A-H3 - Festo 8141094

Festo ✓ Original product Brand new

The vacuum generator OVEL-5-H-10-P-VQ4-UC-C-A-H3 turns compressed air into up to 89 % vacuum and draws up to 4 l/min against atmosphere. Integrated functions: electric ejector pulse, flow control, electric switch-on valve and filter. Maximum vacuum is reached at an operating pressure of just 4.4 bar.

Net
€137.76
excl. VAT
Item FES-8141094
Manufacturer no. OVEL-5-H-10-P-VQ4-UC-C-A-H3
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

At the heart of the OVEL-5-H-10-P-VQ4-UC-C-A-H3 is a Laval nozzle of 0.45 mm nominal size, running on 2 to 7 bar at 4 bar nominal operating pressure. Ejector characteristic: high vacuum, Standard.

Benefits

  • Vacuum up to 89 %, reached at 4.4 bar operating pressure
  • Suction flow up to 4 l/min against atmosphere, at 3 bar operating pressure
  • Clean production: LABS (PWIS) conformity VDMA24364-B1/B2-L
  • Product weight 44 g, grid dimension 10 mm
  • Corrosion resistance class 2 - Moderate corrosion stress
  • Electrics: degree of protection IP40, 24 V DC: 1.0 W

Applications

The high vacuum suits dense, smooth workpieces such as sheet metal, glass or plastic panels. Type of mounting: on manifold rail. Lubricated operation is not possible.

Technical data

Nominal size, Laval nozzle0.45 mm
Grid dimension10 mm
Silencer designClosed
Mounting positionAny
Ejector characteristicHigh vacuum, Standard
Grade of filtration40 µm
Manual overrideNon-detenting
Integrated functionElectric ejector pulse, Flow control, Electric switch-on valve, Filter, Closed silencer
DesignT-shape
Valve functionClosed
Operating pressure for maximum suction flow rate3 bar
Operating pressure2 to 7 bar
Operating pressure for maximum vacuum4.4 bar
Maximum vacuum89 %
Nominal operating pressure4 bar
Maximum suction flow rate against atmosphere4 l/min
Release time at nominal operating pressure with ejector pulse2 s
Operational voltage range DC21.6 to 26.4 V
Duty cycle100 %
Characteristic coil data24 V DC: 1.0 W
Approvalc UL us - Listed (OL)
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation not possible
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Media temperature0 to 50 °C
Sound pressure level at nominal operating pressure51 dB(A)
Degree of protectionIP40
Ambient temperature0 to 50 °C
Product weight44 g
Electrical connection input, functionVacuum generation
Electrical connection input, connection type2x plugs
Electrical connection input, connector systemPlug pattern H
Electrical connection input, number of connections/cores2
Input electrical connection, mounting typeSnap-locking
Type of mountingOn manifold rail
Pneumatic connection, port 1Common line
Pneumatic connection, port 3Closed silencer
Vacuum connectionFor tubing O.D. 4 mm
Material connecting threadPOM
Note on materialsRoHS compliant
Material sealsNBR
Material receiver nozzlePOM
Material filterPOM
Material housingReinforced PA
Material hollow boltWrought aluminium alloy
Material adjusting screwSteel
Material silencerReinforced PA, PE
Material screwsSteel
Material transmitter nozzleWrought aluminium alloy
Weight0.07 kg
ManufacturerFesto
Hersteller-NrOVEL-5-H-10-P-VQ4-UC-C-A-H3
EAN4052568566654
Zolltarifnummer84141089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Seal materialNBR
MediumCompressed air
Functionclosed
Flow rate [l/min]4
Filter grade [µm]40
Operating voltage24 V DC
SeriesOVEL
Betriebsdruck max [bar]7
Protection ratingIP40
Temperaturbereich0-50 °C
Temperature (max.)50
