Round bellows vacuum suction cup Ø 52 mm PUR G3/8 OGVN-52-A-U-G38 - Festo 8204834
The Festo OGVN-52-A-U-G38 vacuum suction cup grips workpieces securely with 90 N of holding force at -0.7 bar nominal operating pressure. Round bellows design made of PUR. Bellows with 1.5 convolutions and 11.2 mm height compensation for uneven or inclined surfaces.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Festo OGVN-52-A-U-G38 vacuum suction cup grips workpieces securely with 90 N of holding force at -0.7 bar nominal operating pressure.
Key benefits
- Holding force of 90 N at a nominal operating pressure of -0.7 bar
- Bellows with 1.5 convolutions and 11.2 mm height compensation for uneven or inclined surfaces
- Suction cup material PUR with Shore hardness A 70 +/-5
- Lateral force of 65 N at nominal operating pressure, relevant for fast sideways moves
- Mounts directly via the G3/8 vacuum connection
Applications
Typical uses are parts with height offsets or slight curvature, such as cartons, bags or plastic mouldings.
Technical data
| Type | OGVN-52-A-U-G38 |
|---|---|
| Festo part number | 8204834 |
| Height compensator for suction cup | 11.2 mm |
| Nominal size | 8 mm |
| Suction cup diameter | 52 mm |
| Suction cup volume | 13.3 cm³ |
| Position of connection | On top |
| Mounting position | Any |
| Suction cup shape | Round, bellows with 1.5 convolutions |
| Operating pressure | -0.95 to 0 bar |
| Nominal operating pressure | -0.7 bar |
| Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-A1/A2-L |
| Suitability for the production of Li-ion batteries | Suitable for battery production with reduced Cu/Zn/Ni values (F1a) |
| Ambient temperature | 10 to 45 °C |
| Holding force at nominal operating pressure | 90 N |
| Lateral force at nominal operating pressure | 65 N |
| Product weight | 14.2 g |
| Type of mounting | Via vacuum port |
| Vacuum connection | G3/8 |
| Colour | Blue/light blue |
| Shore hardness | A 70 +/-5 |
| Material screwed plug | Wrought aluminium alloy |
| Note on materials | RoHS compliant |
| Material suction cup | PUR |
| Weight | 0.03 kg |
| Manufacturer | Festo |
| Hersteller-Nr | OGVN-52-A-U-G38 |
| EAN | 4052568929961 |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | PUR |
| Thread | G 3/8 |
| Nominal size DN [mm] | 8 |
| Diameter [mm] | 52 |
| Medium | Air |
| Pneumatic connection | G3/8 |
| Temperature (max.) | 45 |
