Oval flat vacuum suction cup 20x65 mm NBR G1/4 OGVM-20X65-SV-N-G14F - Festo 8073853

Festo ✓ Original product Brand new

The Festo OGVM-20X65-SV-N-G14F vacuum suction cup grips workpieces securely with 66 N of holding force at -0.6 bar nominal operating pressure. Oval flat design made of NBR. Flat cup with only 3.6 cm³ internal volume for short evacuation times. Suction cup material NBR with Shore hardness 60 +/-5.

Net
€38.17
excl. VAT
Item FES-8073853
Manufacturer no. OGVM-20X65-SV-N-G14F
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo OGVM-20X65-SV-N-G14F vacuum suction cup grips workpieces securely with 66 N of holding force at -0.6 bar nominal operating pressure.

Benefits

  • 66 N holding force at -0.6 bar nominal operating pressure
  • Flat cup with only 3.6 cm³ internal volume for short evacuation times
  • Suction cup material NBR with Shore hardness 60 +/-5
  • Takes up 76 N of lateral force at nominal operating pressure
  • Mounts directly via the female thread G1/4 vacuum connection

Typical applications

Flat suction cups suit smooth, even workpieces such as sheet metal, glass, cardboard or plastic panels.

Technical data

TypeOGVM-20X65-SV-N-G14F
Festo part number8073853
Height compensator for suction cup3 mm
Minimum workpiece radius20 mm
Nominal size6 mm
Suction cup size20x65 mm
Suction cup volume3.6 cm³
Position of connectionOn top
Mounting positionAny
Suction cup shapeOval, flat
Operating pressure-0.95 to 0 bar
Nominal operating pressure-0.6 bar
Operating mediumAtmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-A1-L
Ambient temperature-20 to 80 °C
Holding force at nominal operating pressure66 N
Vertical lateral force at nominal operating pressure76 N
Product weight21 g
Type of mountingVia vacuum port
Vacuum connectionFemale thread G1/4
ColourBlack
Shore hardness60 +/-5
Material screwed plugWrought aluminium alloy
Note on materialsRoHS compliant
Material suction cupNBR
Weight0.022 kg
ManufacturerFesto
Hersteller-NrOGVM-20X65-SV-N-G14F
EAN4052568300937
Zolltarifnummer84799070
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialNBR
ThreadG 1/4 IG
Nominal size DN [mm]6
MediumAir
Thread typeInternal thread
Pneumatic connectionG1/4 IG
Temperaturbereich-20-80 °C
Temperature (max.)80
