Round flat vacuum suction cup Ø 40 mm NBR with rectangular adapter OGVM-40-S-N-RA - Festo 8213218

Festo ✓ Original product Brand new

With 53 N of holding force at -0.6 bar, the Festo OGVM-40-S-N-RA vacuum suction cup (Ø 40 mm) holds parts reliably during handling. Round flat design made of NBR. Low internal volume of 4.4 cm³ in a flat design, so the vacuum builds up quickly. Suction cup material NBR with Shore hardness 60 +/-5.

Net
€37.88
excl. VAT
Item FES-8213218
Manufacturer no. OGVM-40-S-N-RA
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

With 53 N of holding force at -0.6 bar, the Festo OGVM-40-S-N-RA vacuum suction cup (Ø 40 mm) holds parts reliably during handling.

Benefits

  • Holding force of 53 N at a nominal operating pressure of -0.6 bar
  • Low internal volume of 4.4 cm³ in a flat design, so the vacuum builds up quickly
  • Suction cup material NBR with Shore hardness 60 +/-5
  • Takes up 53 N of lateral force at nominal operating pressure
  • Rectangular adapter RA for positive-locking mounting in the holder

Applications

Flat suction cups suit smooth, even workpieces such as sheet metal, glass, cardboard or plastic panels.

Technical data

TypeOGVM-40-S-N-RA
Festo part number8213218
Height compensator for suction cup4 mm
Minimum workpiece radius37.5 mm
Nominal size4 mm
Suction cup diameter40 mm
Suction cup volume4.4 cm³
Position of connectionOn top
Mounting positionAny
Suction cup shapeRound, flat
Operating pressure-0.95 to 0 bar
Nominal operating pressure-0.6 bar
Operating mediumAtmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-A1/A2-L
Ambient temperature-20 to 80 °C
Holding force at nominal operating pressure53 N
Lateral force at nominal operating pressure53 N
Product weight24 g
Type of mountingVia vacuum port
Vacuum connectionRectangular adapter RA
ColourBlack
Shore hardness60 +/-5
Material screwed plugWrought aluminium alloy
Note on materialsRoHS compliant
Material suction cupNBR
Weight0.026 kg
ManufacturerFesto
Hersteller-NrOGVM-40-S-N-RA
EAN4052568790462
Zolltarifnummer84799070
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialNBR
Nominal size DN [mm]4
Diameter [mm]40
MediumAir
Temperaturbereich-20-80 °C
Temperature (max.)80
